DIN Type - Product Range of Traction Batteries
| Type 60 Ah | ||||
|---|---|---|---|---|
|
Dimension(mm) Length ± 2 198 *Height(1) ± 2 347.5 *Height(2) ± 2 334.5 *Height(3) ± 2 360 |
Ah(C5) | Width (mm) | Weight in Kg (± 5%) | |
| With Electrolyte | Without Electrolyte | |||
| 2BPzS120 | 120 | 47 | 8.7 | 7.0 |
| 3BPzS180 | 180 | 65 | 12.4 | 9.7 |
| 4BPzS240 | 240 | 83 | 16.2 | 12.6 |
| 5BPzS300 | 300 | 101 | 19.7 | 15.2 |
| 6BPzS360 | 360 | 119 | 23.3 | 18.4 |
| 7BPzS420 | 420 | 137 | 27.0 | 21.2 |
| 8BPzS480 | 480 | 155 | 30.8 | 23.5 |
| 9BPzS540 | 540 | 173 | 33.7 | 25.6 |
| 10BPzS600 | 600 | 191 | 38.4 | 29.2 |
| Type 80 Ah | ||||
|---|---|---|---|---|
|
Dimension(mm) Length ± 2 198 *Height(1) ± 2 409.5 *Height(2) ± 2 396.5 *Height(3) ± 2 422 |
Ah(C5) | Width (mm) | Weight in Kg (± 5%) | |
| With Electrolyte | Without Electrolyte | |||
| 2BPzS160 | 160 | 47 | 10.5 | 8.0 |
| 3BPzS240 | 240 | 65 | 15.0 | 11.4 |
| 4BPzS320 | 320 | 83 | 19.3 | 14.6 |
| 5BPzS400 | 400 | 101 | 24.0 | 18.3 |
| 6BPzS480 | 480 | 119 | 28.4 | 21.6 |
| 7BPzS560 | 560 | 137 | 32.9 | 25.0 |
| 8BPzS640 | 640 | 155 | 37.3 | 28.4 |
| 9BPzS720 | 720 | 173 | 41.3 | 31.2 |
| 10BPzS800 | 800 | 191 | 45.8 | 19.7 |
| Type 90 Ah | ||||
|---|---|---|---|---|
|
Dimension(mm) Length ± 2 198 *Height(1) ± 2 476.5 *Height(2) ± 2 463.5 *Height(3) ± 2 489 |
Ah(C5) | Width (mm) | Weight in Kg (± 5%) | |
| With Electrolyte | Without Electrolyte | |||
| 2BPzS180 | 180 | 47 | 12.6 | 9.1 |
| 3BPzS270 | 270 | 65 | 17.9 | 13.2 |
| 4BPzS360 | 360 | 83 | 22.7 | 16.9 |
| 5BPzS450 | 450 | 101 | 27.6 | 20.6 |
| 6BPzS540 | 540 | 119 | 32.7 | 24.5 |
| 7BPzS630 | 630 | 137 | 37.9 | 28.4 |
| 8BPzS720 | 720 | 155 | 43.1 | 32.3 |
| 9BPzS810 | 810 | 173 | 47.7 | 36.5 |
| 10BPzS900 | 900 | 191 | 52.8 | 39.8 |
| Type 105 Ah | ||||
|---|---|---|---|---|
|
Dimension(mm) Length ± 2 198 *Height(1) ± 2 525.5 *Height(2) ± 2 512.5 *Height(3) ± 2 538 |
Ah(C5) | Width (mm) | Weight in Kg (± 5%) | |
| With Electrolyte | Without Electrolyte | |||
| 2BPzS210 | 210 | 47 | 13.4 | 9.5 |
| 3BPzS315 | 315 | 65 | 19.4 | 14.2 |
| 4BPzS420 | 420 | 83 | 25.1 | 18.7 |
| 5BPzS525 | 525 | 101 | 30.9 | 23.1 |
| 6BPzS630 | 630 | 119 | 36.6 | 27.6 |
| 7BPzS735 | 735 | 137 | 42.6 | 32.4 |
| 8BPzS840 | 840 | 155 | 48.4 | 36.8 |
| 9BPzS945 | 945 | 173 | 54.3 | 41.5 |
| 10BPzS1050 | 1050 | 191 | 60.1 | 45.9 |
| Type 115 Ah | ||||
|---|---|---|---|---|
|
Dimension(mm) Length ± 2 198 *Height(1) ± 2 556.5 *Height(2) ± 2 543.5 *Height(3) ± 2 569 |
Ah(C5) | Width (mm) | Weight in Kg (± 5%) | |
| With Electrolyte | Without Electrolyte | |||
| 2BPzS230 | 230 | 47 | 15.0 | 11.6 |
| 3BPzS345 | 345 | 65 | 21.3 | 16.8 |
| 4BPzS460 | 460 | 83 | 27.3 | 21.0 |
| 5BPzS575 | 575 | 101 | 33.4 | 25.8 |
| 6BPzS690 | 690 | 119 | 39.8 | 31.1 |
| 7BPzS805 | 805 | 137 | 46.0 | 36.2 |
| 8BPzS920 | 920 | 155 | 52.3 | 40.8 |
| 9BPzS1035 | 1035 | 173 | 59.5 | 46.5 |
| 10BPzS1150 | 1150 | 191 | 64.6 | 50.3 |
| Type 125 Ah | ||||
|---|---|---|---|---|
|
Dimension(mm) Length ± 2 198 *Height(1) ± 2 581.5 *Height(2) ± 2 568.5 *Height(3) ± 2 594 |
Ah(C5) | Width (mm) | Weight in Kg (± 5%) | |
| With Electrolyte | Without Electrolyte | |||
| 2BPzS250 | 250 | 47 | 15.4 | 12.2 |
| 3BPzS375 | 375 | 65 | 21.8 | 16.9 |
| 4BPzS500 | 500 | 82 | 28.1 | 22.1 |
| 5BPzS625 | 625 | 101 | 34.7 | 27.8 |
| 6BPzS750 | 750 | 119 | 41.2 | 31.8 |
| 7BPzS875 | 875 | 137 | 47.8 | 37.0 |
| 8BPzS1000 | 1000 | 155 | 54.4 | 42.3 |
| 9BPzS1125 | 1125 | 173 | 60.8 | 49.4 |
| 10BPzS1250 | 1250 | 191 | 67.2 | 53.6 |
| Type 140 Ah | ||||
|---|---|---|---|---|
|
Dimension(mm) Length ± 2 198 *Height(1) ± 2 697.5 *Height(2) ± 2 684.5 *Height(3) ± 2 710 |
Ah(C5) | Width (mm) | Weight in Kg (± 5%) | |
| With Electrolyte | Without Electrolyte | |||
| 2BPzS280 | 280 | 47 | 18.5 | 14.0 |
| 3BPzS420 | 420 | 65 | 27.3 | 20.9 |
| 4BPzS560 | 560 | 83 | 35.4 | 26.4 |
| 5BPzS700 | 700 | 101 | 42.9 | 33.6 |
| 6BPzS840 | 840 | 119 | 50.8 | 38.7 |
| 7BPzS980 | 980 | 137 | 59.0 | 44.3 |
| 8BPzS1120 | 1120 | 155 | 67.1 | 51.0 |
| 9BPzS1260 | 1260 | 173 | 74.3 | 57.6 |
| 10BPzS1400 | 1400 | 191 | 84.1 | 63.5 |
| Type 155 Ah | ||||
|---|---|---|---|---|
|
Dimension(mm) Length ± 2 198 *Height(1) ± 2 726.5 *Height(2) ± 2 713.5 *Height(3) ± 2 739 |
Ah(C5) | Width (mm) | Weight in Kg (± 5%) | |
| With Electrolyte | Without Electrolyte | |||
| 2BPzS310 | 310 | 47 | 19.4 | 15.2 |
| 3BPzS465 | 465 | 65 | 27.8 | 21.4 |
| 4BPzS620 | 620 | 83 | 36.2 | 27.7 |
| 5BPzS775 | 775 | 101 | 44.1 | 34.1 |
| 6BPzS930 | 930 | 119 | 52.8 | 41.3 |
| 7BPzS1085 | 1085 | 137 | 61.2 | 48.2 |
| 8BPzS1240 | 1240 | 155 | 69.7 | 56.3 |
| 9BPzS1395 | 1395 | 173 | 78.0 | 59.9 |
| 10BPzS1550 | 1550 | 191 | 86.4 | 66.0 |
