BPS10-12 BPS Series - For General Use
额定容量: | 1(20Hr), 1(10Hr), 1(5Hr), 1(1Hr) |
重量: | 3.30kg (7.28lbs) |
尺寸: |
151L x 65W x112H x 116TH (mm) 5.94L x 2.56W x4.41H x 4.57TH (inch) |
BPS10-12 BPS Series - For General Use
• Maintenance free(no water topping-up required).
• No free acid(Non-spillable battery).
• Low self-discharge rate, lower than 3% capacity loss per month.
• Can be used in any orientation(excluding used inverted).
• Absorbent Glass Mat technology for efficient gas recombination.
Internal Resistance: ≦27mΩ ( Fully Charged )
Operating Temperature Range:
Charge 0°C~40°C(32°F~104°F)
Discharge -20°C~50°C(-4°F~122°F)
Storage. -20°C~40°C(-4°F~104°F)
Container Material: Standard: ABS( UL 94-HB) BP7-12 Optional: Flame Retardant ABS(UL 94-V0) BP7-12FR
All data and artworks shall be changed without prior notice, BB reserves the right to explain and update the information contained hereinto.
电压 : 12 V
额定容量 : 1(20Hr), 1(10Hr), 1(5Hr), 1(1Hr)
重量 : 3.30kg (7.28lbs)
尺寸 : 151L x 65W x112H x 116TH (mm)
5.94L x 2.56W x4.41H x 4.57TH (inch)
端子类型 : T2 (Faston Tab 187) T1 is optional
5秒钟放电最大电流 :105 A (5 sec.)
最大充电电流 : 3.0 A
应用范围 : 不间断电源, 实验室设备
