Solar
Please Select Series in the box.Result:0
VRLA-GEL
- Zelus - GBS Series/ GBS Series
Traction Battery
- Spur Series - BS Type/ BS Type
- Spur Series - DIN Type/ DIN Type
| Model | Voltage | Nominal Capacity(Ah) | Weight | Terminal | Dimension | Model Download |
|||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Standard | Optional | L | W | H | TH | ||||||||||||
| 100Hr | Kg | Lbs | Type | Position | Type | Position | mm | inch | mm | inch | mm | inch | mm | inch | |||
| GBS12/75 | 12 V | 75 | 24 | 52.91 | I2 | 259.5 | 10.22 | 172.6 | 6.80 | 200.5 | 7.89 | 217.0 | 8.54 | GBS12/75 | |||
| GBS12/85 | 12 V | 85 | 29.5 | 65.04 | I2 | 329 | 12.95 | 172 | 6.77 | 214.5 | 8.44 | 219 | 8.6 | GBS12/85 | |||
| GBS12/7 | 12 V | 7 | 2.45 | 54.01 | T2 | T1 | 151 | 5.94 | 65 | 2.56 | 93 | 3.66 | 98 | 3.86 | GBS12/7 | ||
| GBS12/33 | 12 V | 33 | 11.3 | 24.91 | B7 | I2 | 195 | 7.68 | 129 | 5.08 | 168 | 6.64 | 178.6 | 7.03 | GBS12/33 | ||
| GBS12/120 | 12 V | 120 | 39 | 8.98 | I2 | 407 | 16.02 | 173 | 6.81 | 210 | 8.27 | 239 | 9.41 | GBS12/120 | |||
| GBS12/130 | 12 V | 130 | 40 | 88.1 | I2 | 344 | 13.54 | 172 | 6.77 | 263.8 | 10.39 | 280.3 | 11.04 | GBS12/130 | |||
| GBS12/170 | 12 V | 170 | 55 | 121.3 | B9 | I3 | 522 | 20.55 | 202 | 7.95 | 216 | 8.50 | 219.5 | 8.64 | GBS12/170 | ||
| GBS12/225 | 12 V | 225 | 67.5 | 148.8 | B9 | I3 | 522 | 20.55 | 240 | 9.54 | 216 | 8.50 | 219.5 | 8.64 | GBS12/225 | ||
| GBS6/215 | 6 V | 215 | 32.8 | 72.31 | I3 | I4 | 244 | 9.61 | 190.0 | 7.48 | 275.0 | 10.83 | 275.0 | 10.83 | GBS6/215 | ||
| GBS12/43.5 | 12 V | 43.5 | 16.1 | 52.91 | I2 | 197 | 7.76 | 165 | 6.50 | 171 | 6.73 | 171 | 6.73 | GBS12/43.5 | |||
| GBS12/110 | 12 V | 110 | 35.5 | 78.26 | B3 | I2 | 330 | 12.99 | 173 | 6.81 | 212 | 8.35 | B3:241, I2:218 | B3:9.49, I2:8.59 | GBS12/110 | ||
Model
|
Cell Capacity Ah(C5) |
Dimension (mm) | Weight in Kg (±5%) | Model Download |
|||||
|---|---|---|---|---|---|---|---|---|---|
| L | W | H(1)
|
H(2)
|
H(3)
|
With Electrolyte |
Without Electrolyte |
|||
| 2BPzB64 - BS Type 32Ah | 64 | 158 | 46 | 271 | 259 | 4.6 | 3.5 | Spur Series - BS Type | |
| Model
|
Cell Capacity Ah(C5) |
Dimension (mm) | Weight in Kg (±5%) | Model Download |
|||||
|---|---|---|---|---|---|---|---|---|---|
| L | W | H(1)
|
H(2)
|
H(3)
|
With Electrolyte |
Without Electrolyte |
|||
| 2BPzS200 - DIN Type 50Ah | 83 | 198.5 | 83 | 300 | 12.0 | 10.0 | Spur Series - DIN Type | ||
