EP Series - For High Cycle Use
EP Series - For High Cycle Use

EP65-12 EP Series - For High Cycle Use

Voltage： 12 V
Nominal Capacity： 1(20Hr), 1(5Hr)
Approx. Weight： 25.00kg (55.13lbs)
Dimensions： 350L x 166 W x174H x 174TH (mm)
13.78L x 6.54W x6.85H x 6.85TH (inch)
Application： Golf Cart, UPS, Wheelchair, Lawn Mower, Electric Vehicle
Terminal： I2 (optional),  B5

Specification Download

EP65-12 EP Series - For High Cycle Use

• Absorbent Glass Mat technology for efficient gas recombination
• Maintenance free(no water topping-up required)
• No free acid(Non-spillable battery)
• Can be used in any orientation(excluding used inverted)
• The battery is designed for heavy duty cyclic application
• Low self-discharge rate, lower than 3% capacity loss per month

Internal Resistance: ≦6mΩ ( Fully Charged )

Operating Temperature Range:

Charge 0 C~40 C(32 F~104 F)

 Discharge -20 C~50 C(-4 F~122 F)

Storage. -20 C~40 C(-4 F~104 F)

Container Material:  Standard: ABS( UL 94-HB) EP65-12  Optional: Flame Retardant ABS(UL 94-V0) EP65-12FR



All data and artworks shall be changed without prior notice, BB reserves the right to explain and update the information contained hereinto.


Voltage : 12 V

Nominal Capacity : 1(20Hr), 1(5Hr)

Approx. Weight : 25.00kg (55.13lbs)

Dimensions : 350L x 166 W x174H x 174TH (mm)
                        13.78L x 6.54W x6.85H x 6.85TH (inch)

Terminal : B5 (Fitting M6 bolt & nut) I2 is optional

Max Discharge Current for 5 Sec :650 A (5 sec.)

Max Charge Current : 19.5 A

Application : Golf Cart, UPS, Wheelchair, Lawn Mower, Electric Vehicle
